Cisco Codian IP VCR 2220 Telepresence Video Conference Streaming Recorder

P VCR 2200 Series Specifications Model 2210 2220 2240 H.323 Recording Ports 1 5 10 H.323 Playback Ports 5 10 20 Video Streaming (Unicast/Multicast) 100/Unlimited 200/Unlimited 400/Unlimited Recorded Hours (High/Med./Low Quality) 75/150/300 150/300/600 300/600/1200 Video Firewall No Included Included Video Standards H.261, H.263, H.263+, H.263++, H.264, MPEG-1 Video Resolution QCIF, QSIF, CIF, SIF, iCIF, iSIF, 288p, 384p, 400p, 448p, VGA, 4CIF, 4SIF, 480p, SVGA, 576p, XGA, 720p Audio Standards G.711, G.722, G.723.1, G.728, G.729, MPEG-4 AAC-LC, MPEG-4 AAC-LD, Polycom® Siren14™ / G.722.1 Annex C Frame Rates Up to 30 frames or 60 fields per second in all modes Bandwidth from 128kbit/s to 2 Mbit/s Transcoding and Transrating Video and audio are played back via H.323 or streamed using a bandwidth and codec that can be different from the source The IP VCR will transcode and transrate as required All recordings are stored in native format with no loss of quality Recording From an H.323 endpoint, MCU or Gateway From two H.323 endpoints on a point to point call H.323 dial in, or dial out from web server Data from H.239 (dual video) capable endpoints Up to 200 recordings Folders for structured storage Streaming Video Pause, rewind and fast forward for recorded playback Embedded via web interface or standalone via URL Viewed using Windows Media Player™, RealPlayer™ or QuickTime™ Stream at multiple bandwidths Support for 3rd party streaming servers Unicast or Multicast UDP, TCP or HTTP H.323 Playback To H.323 endpoint, MCU or Gateway Select using E.164 address, using auto attendant or dial out from web server Replay of data / slides using H.239 (dual video) Choose side by side or PiP (voice activated) layout for playback of point to point recordings Pause, rewind and fast forward using remote control Bandwidth / codec adjusted to match endpoint and network Built-in and uploadable auto attendant voice prompts Export Recordings Export in industry standard MPEG-1 to easily create CDs or DVDs Import Video Upload industry standard MPEG-1 video presentations System Management RS-232 for local control and diagnostics Secure upgrades through Ethernet or CompactFlash Configurable event logs and full H.323 and SIP decoding Configuration Backup to network SNMP Interfaces 2 x RJ45 Ethernet 10/100/1000 Mbps full/half duplex: manual or autosensing RJ45 serial port CompactFlash socket 37 status LEDs Security Features Administrator, User and Guest passwords Password protected streaming and content playback DTMF passwords for H.323 endpoints Secure non-PC hardware and operating system Video firewall option using second Ethernet port Physical Dimensions 19” rack mountable (kit supplied) or standalone Height 1.73”, 44 mm (1U), Width 17.2”, 437 mm Depth 12.3”, 312 mm, Weight 9 lbs, 4kg Power 100-240 VAC, 50/60Hz 110W max power consumption
